Ultimate Power Amp

1450 2900

EAN: 5905481303204 Category: SKU: N/A

Description

Hattor Ultimate Power Amplifier uses the latest nCore™ amplifier technology licensed from Hypex to provide a nearly ideal amplifier with distortion below measurement, ultra-high damping factor, and unconditional stability with any speaker.

Tight, detailed sound with amazing control and transparency gets the best performance available.



Custom made buffer with best parts possible

Staccato opamps

Hypex super low noise voltage regulators

AMRT resistors

Hattor pattented pure copper speaker terminals
Neutrik XLR connectors
CMC RCA sockets

RCA input is converted to balanced signal



Specification:

Output power: 400 W/8 ohm, 700W/4 ohm, 550W/2 Ohm
Gain: 26 dB
Signal/Noise Ratio: 125 dB
Distortion (THD, IMD): 0.001 %
Input Impedance: 47 kohm
Output Impedance: 0.005 ohm
Frequency Response: 2Hz – 50kHz 0/-3db
Speaker connection : Pure copper patented Hattor binding posts
Dimensions: 90 x 270 x 250 (H x W x D)

Additional information

Weight 6 kg
Dimensions 400 × 500 × 120 mm
Channels

-, 1 Monoblock, 2 Monoblocks

Chassis color

-, Silver, Black

Front panel

-, Silver outline + silver inside, Silver outline + black inside, Silver outline + wood inside, Silver outline + gold inside, Black outline + silver inside, Black outline + black inside, Black outline + wood inside, Black outline + gold inside

Voltage

-, 230V, 110V
